S1097
详细介绍
Introduction
No. S1097
Product Name S1097
Description
Zinc alloy die cast housing and cylinder.
Bright chrome plated standard.
No pin tumbler mechanism.
Zinc alloy tubular keys, chrome plated.
“L” dimension 13mm standard; other dimensions available upon request.
Dual-functioned Key Lock Switch.
Silver plated contacts and terminals.
2 position (off-on) 2 terminals.
Hex nut or speed clip mounted.
产品型号：S1097
产品名称：KEYLOCK SWITCH
产品说明：
锌合金锁壳，锁心，亮铬电镀
机械锁珠子
锌合金管钥匙，镀铬
铁棒标准规格为13mm，另可依客户要求制作
电源及挡片双功能锁
钥匙双抽
镀银接点及端子
2支端子，通电方式OFF-ON
锁头固定方式为六角螺母或插片
规格品为同号或6组钥匙组合
最多有6组钥匙组合
